FUSE 350A TIME DELAY RK5 CLASS FRN-R-350

Be the first to review this product

SKU: FRN-R-350 UPC: 051712507523 Categories: ELECTRICAL, FUSES

FRN-R-350

Eaton Bussmann Series Class RK5 fuse, FRN-R, time-delay, dual-element, current limiting fuse, 350 A, non-indicating fuse, interrupting rating of 200 kA at 250 Vac and 20 kA at 250 Vdc

Log in to see prices
or
Request A Quote
or
Buy Now

Description

General specifications

Product Name
Eaton Bussmann series FRN-R fuse
Catalog Number
FRN-R-350
UPC
051712507523
Product Length/Depth
8.63 in
Product Height
2.38 in
Product Width
2.38 in
Product Weight
1.95 lb
Warranty
Not Applicable
Compliances
CE Marked

Electrical rating

Amperage Rating
350 A
Interrupt rating
20 kAIC at 125 Vdc
200 kAIC at 250 Vac
Response time
10 sec at 500%
Voltage rating
250 Vac, 125 Vdc

Physical details

Number of elements
Dual
Packaging type
Standard

General information

Class
Class RK5
Connection
Blade end x blade end
Fuse indicator
Non-indicating
Special features
Finger safe

Additional information

Weight 1.9500 lbs
Dimensions 8.63000 × 2.38000 × 2.38000 in
